Rail Lubricator – Y145
The Y145 rail lubricator features a 125 ml oil capacity, a high-strength polypropylene body, and a specially engineered wool felt system. Its drip-free design supports efficient oil use and helps maintain consistent lubrication during operation.
It is suitable for flat and L-shaped guide shoes used with 5–29 mm rail widths.
> Maximum lubrication performance with wool felt
> Drip-free compact design
> Lubrication by the capillary action principle
> 125 ml oil volume
Rail Lubricator Y145 Specifications
High-strength virgin polypropylene body
125 ml oil volume · Wool felt
145 x 42 x 121 mm
The wool felt used in the Y145 model ensures effective oil transfer to the guide rail surface thanks to its high oil absorption and intensive delivery capability. This structure provides maximum and uniform lubrication, reducing wear and extending system service life.
Its single-piece, compact design is oil-tight. Operating on the capillary action principle, it enables controlled oil transfer while reducing oil consumption.
With its easy installation feature and perfect compatibility with TMS Lift guide holders, it allows fast and secure installation.
Product Name | Rail Lubricator Y145 |
Product Type | Elevator rail lubricator |
Oil Volume | 125 ml |
Material | High-strength virgin polypropylene |
Felt Material | Wool |
Weight | 0.1 kg |
Suitable Guide Shoes | 140 030, 140 030 L, 180 030, 180 030 L, 180 050, 180 050 L, 300 030 |
Rail Width | 5 – 29 mm |
Body Dimensions (L × W × H) | 145 x 42 x 121 mm |
